7 1/4" Sit Astride Bogie Coach

Click to enlargeClick to enlarge



  • Bogie wheel size 127mm (cut from 5" dia blank) EN8 steel
  • 1" diameter axles
  • Length 2400 mm
  • Width 595mm
  • Minimum radius - 20 feet (4.5m)

Optional Extras

  • Braking Systems
  • Different lengths/widths
  • Shoe brakes - Vacuum or air
  • Pass through electrics
  • Vinyl wrap and sign writing
  • HDPE - high density plastic coloured end panels
  • One piece zinc plated sides - no maintenance
  • 350mm foot to seat height for comfortable seating position
  • Lift off seats for access to bogies
Theses coaches were designed to for low maintenance and bring out the best features of a sit astride coach.

Using 3mm zinc plated combinded foot rest and sides provides a sturdy heavy construction that makes for a very stable coach that allows four large adults (more if they cuddle up) or a lot more children.
